TPS7A7001DDAR

Specifications

Polarity: Positive
Output Type: Adjustable
Unit Weight: 70.600 mg
Mounting Style: SMD/SMT
Output Current: 2 A
Output Voltage: 500 mV to 5 V
Development Kit: TPS7A7001EVM-065
Dropout Voltage: 200 mV
Line Regulation: 0.4 %/V
Load Regulation: 0.75 %/A
Number of Outputs: 1 Output
Quiescent Current: 1 uA
Moisture Sensitive: Yes
Input Voltage - Max: 6.5 V
Input Voltage - Min: 1.425 V
Operating Supply Current: 3 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
